QS-GF(20-50)型旋转接头适用范围：
转速：100RPM
温度：220℃
压力：1.8MPa
适用介质：饱和蒸汽、过热蒸汽、过热水
双向流通内管固定式——半分环法兰连接
|
规格
|
型号
|
B
|
C
|
D
|
E
|
F1
|
F2
|
H
|
I1
|
I2
|
J
|
K
|
L
|
L1
|
L2
|
L4
|
L5
|
M1
|
M2
|
N
|
O
|
P
|
Q
|
R
|
S
|
T
|
U
|
|
20
|
QS-GF20-8
|
G1/4
|
Rc3/4
|
Rc1/2
|
96
|
48
|
30
|
58
|
12
|
12
|
25
|
35
|
210
|
195
|
171
|
133
|
55
|
104
|
-
|
18
|
27
|
75
|
105
|
16
|
8
|
4
|
14
|
|
25
|
QS-GF25-10
|
G3/8
|
Rc3/4
|
Rc1/2
|
76
|
35
|
33
|
54
|
14
|
14
|
26
|
35
|
240
|
225
|
215
|
165
|
47
|
-
|
95
|
25
|
33.5
|
85
|
115
|
16
|
8
|
4
|
14
|
|
32
|
QS-GF32-15
|
G1
/2 |
Rc1
|
Rc1/2
|
120
|
63
|
38
|
70
|
14
|
14
|
26
|
47
|
254
|
239
|
237
|
156
|
62
|
-
|
98
|
30
|
42
|
100
|
140
|
18
|
12
|
4
|
18
|
|
40
|
QS-GF40-20
|
G3
/4 |
Rc1-1/4
|
Rc3/4
|
130
|
70
|
43
|
78
|
16
|
16
|
32
|
45
|
291
|
273
|
269
|
187
|
69
|
-
|
125
|
38
|
48
|
110
|
150
|
18
|
12
|
4
|
18
|
|
50
|
QS-GF50-25
|
G1
|
Rc1-1/2
|
Rc1
|
160
|
80
|
51
|
80
|
18
|
18
|
35
|
36
|
315
|
295
|
274
|
199
|
70
|
138
|
-
|
48
|
60
|
125
|
165
|
20
|
15
|
4
|
1
|
